Professional Dual Handheld Wireless System
The spiritvox SV-700 represents the pinnacle of wireless microphone technology, combining premium beta capsules with advanced digital UHF transmission for uncompromising audio quality. Designed for demanding professional applications where vocal clarity is paramount.
Microphone Specifications
- Capsule Type: Professional Beta Series
- Frequency Response: 40Hz-20kHz (±2dB)
- Sensitivity: -54dB ±2dB (1V/Pa at 1kHz)
- Dynamic Range: 120dB (A-weighted)
Advanced Electronics
- Preamp: Ultra-low noise Class-A
- AD Conversion: 24-bit/48kHz
- THD: 0.5% @ 1kHz
- SNR: >110dB
Wireless System
- Frequency Range: UHF 470-960MHz
- Channels: 500 programmable
- Encryption: 256-bit digital
- RF Power: 10/20/30mW adjustable
Display Features
- Display Type: LCD
- Information: RF/audio levels, battery, frequency
- Polar Pattern: Super-cardioid
- Latency: 3ms
Technical Specifications
Detailed technical specifications for SV-700 system
| Frequency Band |
UHF 470-960MHz |
| Modulation |
Digital FM with error correction |
| RF Power |
10/20/30mW adjustable |
| Audio Output |
Dual XLR balanced + 6.35mm unbalanced |
Recommended Applications
Live Concerts
Broadcast Studios
Professional Recording
Theater Productions
Corporate Events
Worship Facilities
